Bespoke Roof Access Hatch
£0.00
-
Weight
-
Manufacturer
-
Product Material
-
Model Number
-
Additional Information
-
Image Information
If you already have the upstand for your roof hatch a Standard Roof Access Hatch will not necessarily work. If you already have the upstand of the hatch please complete the Existing Upstand Data Form and drop us an email for a quote. We also supply bespoke roof hatches that can come complete with a guardrail and/or an electric control box. We will provide a CAD drawing to be approved before manufacturing can commence with all bespoke hatches.
If you are unsure exactly what you require please don't hesitate to get in touch, you can e-mail us at sales@ladderstore.com or give us a call.
Other Important Information
- As standard, our roof hatches are supplied unpainted in a milled finish.
- Hatches are manufactured from 2mm Aluminium with a natural industrial-grade finish.
- Hatch lids comprise an aluminium envelope enclosing 60mm of Phenolic insulation, the u-value of the Phenolic insulation is 0.35u as a standalone insulant.
- The minimum Up-stand height to comply with building regulations is 150mm from the roof deck. The Up-stand is also insulated with 60mm Phenolic insulation and pre-drilled with all required fixing holes. Various Up-stands are available.
- Rubber seals between the lid and upstand prevent the ingress of rain
- All components are manufactured from stainless steel except the gas struts and the plastic inner handle. The gas struts can be specified in stainless steel for corrosive or high salt environments
- All other ironmongery including screws, brackets, rivets and hinges are either aluminium or stainless steel.
- Internal locking is provided by a stainless steel hasp and staple to accept a padlock.
- The hatch has a combination of gas struts to balance the opening and to hold the lid in the open position.
Please Note: This product is made to order and is non-returnable.
